Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Double Acting Oil Return, Plain Ram, Hydraulic Jacks (DAP-Series)
Capacity : 10-1000 tons Stroke : 150 mm Working : 700 bar (Max)
Features / Benefits
High strength, alloy steel body.
Hard chrome plated ram to resist scoring and corrosion.
Ideal for heavy duty application.
QCC with Plastic dust cap.
High pressure long life seals.
Bottom mounting holes for bolting.
Wiper to arrest ingress of foreign particles.
Safety valve in return line prevents pressure intensification in annular area.
Adequate gripping by grooved saddle.
Port Size 3/8" NPT.
Customised capacity, strokes, collar threading and tilting saddle available on request.
Application :
These jacks are designed to provide force in any direction of the ram. These are mainly used in hydraulic testing machines, lifting, lowering, spreading, shifting of bridges, heavymachinery etc.
MODEL NO. |
Cap. Fwd. |
Cap. Rtn. |
Closed Ht. 'CH' |
Stroke 'S' |
Ram Dia 'RD' |
Outer Dia 'D' |
Forward Volume |
Return Volume |
Approx Weight |
Suitablr Hand Pump |
tons. |
tons. |
mm. |
mm. |
mm. |
mm. |
cc. |
cc. |
kgs. |
||
DAP-10/150 |
10 |
2.2 |
295 |
150 |
30 |
75 |
247 |
137 |
9 |
PHP-200/2 DCV |
DAP-15/150 |
15 |
2.8 |
300 |
150 |
40 |
85 |
368 |
174 |
11 |
PHP-200/2 DCV |
DAP-20/150 |
20 |
3.8 |
305 |
150 |
45 |
95 |
480 |
235 |
14 |
PHP-200/2 DCV |
DAP-25/150 |
25 |
4.7 |
310 |
150 |
50 |
95 |
593 |
290 |
16 |
PHP-400/3N DCV |
DAP-30/150 |
30 |
3.9 |
320 |
150 |
60 |
105 |
685 |
247 |
18 |
PHP-400/3N DCV |
DAP-50/150 |
50 |
7.0 |
330 |
150 |
80 |
130 |
1217 |
438 |
28 |
PHP-400/3N DCV |
DAP-75/150 |
75 |
10.5 |
340 |
150 |
95 |
160 |
1742 |
650 |
43 |
PHP-500/6DCV |
DAP-100/150 |
100 |
16.8 |
350 |
150 |
105 |
175 |
2386 |
1044 |
55 |
PHP-500/6DCV |
DAP-150/150 |
150 |
28.5 |
360 |
150 |
120 |
215 |
3518 |
1765 |
100 |
PHP-500/6DCV |
DAP-200/150 |
200 |
34.4 |
380 |
150 |
150 |
250 |
4879 |
2130 |
120 |
PHP-500/12DCV |
DAP-250/150 |
250 |
50.8 |
400 |
150 |
150 |
285 |
5892 |
3153 |
170 |
PHP-500/12DCV*PP |
DAP-300/150 |
300 |
56.3 |
410 |
150 |
170 |
310 |
7012 |
3494 |
200 |
PHP-500/12DCV*PP |
DAP-400/150 |
400 |
59.0 |
420 |
150 |
220 |
360 |
9544 |
3652 |
290 |
PHP-500/20DCV*PP |
DAP-500/150 |
500 |
66.0 |
450 |
150 |
250 |
400 |
11699 |
4090 |
425 |
PHP-500/20DCV*PP |
DAP-600/150 |
600 |
73.0 |
475 |
150 |
280 |
440 |
14073 |
4529 |
490 |
PHP-500/24*PP |
DAP-800/150 |
800 |
122.0 |
500 |
150 |
300 |
510 |
18516 |
7560 |
700 |
*PP |
DAP-1000/150 |
1000 |
157.0 |
540 |
150 |
350 |
580 |
24652 |
9739 |
950 |
*PP |
 |
 |
