Capacity : 10-100 tons, Stroke : 50-150 mm, Working Pr.: 700 bar (Max)
We are Manufacturer, Supplier, Exporter of: Puller Attachment operated with separate hand pumps from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
All dimensions are in mmThe combination of hollow ram jacks, hand pump, gauge, flexible hose, center screw with speed nut, grip pullers (2 jaws and 3 jaws), push pullers, bearing puller and internal cup puller attachments forms a master puller. The versatile sets offer unmatched application in the maintenance and repair field. To make a Master puller set, choose the capacity required in the individual attachments.
Thumb rule for Puller selectionTo determine the max. force required to overcome the resistance, multiply shaft diameter in mm. by 40 and multiply the results thereof by 8 which gives you capacity of the puller to be used in kgs. For tons. divide kgs. by 1000.
ApplicationThese puller attachments are combined with hollow jacks and other accessories for removing gears, bearings, pullers, pulleys etc.
Grip Puller (GP-Series)
Capacity |
Attachment Model No. |
Use with Hyd. Jack. |
Reach Max. |
Spread Max. |
10 |
2GP 10 |
CHS 10 |
180 |
250 |
10 |
3GP 10 |
CHS 10 |
180 |
300 |
20 |
2GP 20 |
CHS 20 |
180 |
325 |
20 |
3GP 20 |
CHS 20 |
180 |
400 |
30 |
2GP 30 |
CHS 30 |
325 |
500 |
30 |
3GP 30 |
CHS 30 |
325 |
550 |
50 |
2GP 50 |
CHS 50 |
390 |
700 |
50 |
3GP 50 |
CHS 50 |
390 |
800 |
100 |
3GP 100 |
CHS 100 |
800 |
1200 |
Bearing Puller (BP-Series)
Capacity |
Attachment Model no |
Use with Hyd. Jack |
Reach Max. |
Spread Min-Max |
10 |
BP 10 |
CHS 10 |
100 |
10-110 |
20 |
BP 20 |
CHS 20 |
150 |
15-215 |
30 |
BP 30 |
CHS 30 |
250 |
20-250 |
50 |
BP 50 |
CHS 50 |
400 |
50-400 |
100 |
BP 100A |
CHS 100 |
625 |
100-500 |
100 |
BP 100B |
CHS 100 |
795 |
150-850 |
Internal Puller (IP-Series)
Capacity |
Attachment Model no |
Use With Hyd. Jack. |
Reach Max |
Spread Max |
10 |
IP 10 |
CHS 10 |
100 |
15-100 |
20 |
IP 20 |
CHS 20 |
130 |
40-150 |
30 |
IP 30 |
CHS 30 |
150 |
65-180 |
Push Puller (PP-Series)
Capacity |
Attachment Model no |
Use With Hyd. Jack. |
Reach Max |
Spred Max |
Tie-rod and Threading |
10 |
BP 10 |
CHS 10 |
150 |
100-250 |
M16 x 2P |
20 |
BP 20 |
CHS 20 |
240 |
150-300 |
M24 x 2P |
30 |
BP 30 |
CHS 30 |
240 |
175-410 |
M24 x 2P |
50 |
BP 50 |
CHS 50 |
340 |
200-410 |
M38 x 3P |
To reduce the closed height of the jack, there is no seal box. One has to monitor the lifting stroke since there would be a chance of ram coming out of the cylinder which would result in a accident and failure of jack. Place rigid base below the jack.
