Hydraulic Workshop Type Press (WTH-Series)

Hydraulic Workshop Type Press
Hydraulic Workshop Type Press Manufacturer


Model
Capacity
Stroke 'A'
Min.Daylight 'B'
Max Daylight 'C'
Daylight setting 'D'
Width between Column 'E'
Depth between Column 'F'
Overall size
G x H x L
Weight Approx.
Tons
MM
MM
MM
MM
MM
MM
MM
KGS.
WTH-10
10
150
200
650
150
600
150
1000 x 1500 x 500
180
WTH-15
15
150
200
650
150
600
150
1000 x 1500 x 500
200
WTH-25
25
150
200
650
150
800
150
1200 x 1700 x 600
250
WTH-40
40
150
200
800
150
915
200
1500 x 1900 x 600
500
WTH-50
50
150
200
800
150
915
200
1500 x 1900 x 700
550
WTH-75
75
150
250
1050
200
915
250
1600 x 2100 x 700
600
WTH-100
100
150
250
1050
200
1015
300
1700 x 2300 x 800
900
WTH-150
150
150
250
1050
200
1015
350
1800 x 2400 x 1000
1200
WTH-200
200
150
250
1050
200
1015
400
1850 x 2400 x 1000
1500

Features / Benefits :
Single acting spring return / Double acting oil return
Cylinder honed to asurface finish 0.4 microns.
Hard chrome plated ram to resist scoring and corrosion.
Wiper to arrest ingress of foreign particles.
Working pressure 450-700 Bar
Operated by hand Pump / Power pack
Mechanical winch and 'V' blocks shall be provided upto 100 T capacity presses only.

Other Hydraulic Press

hydraulic-roll-frame-press

Hydraulic Roll Frame Press

closed-frame-hyd-press

Closed Frame Hydraulic Press

Four Pillar Hydraulic Press

Four Pillar Hydraulic Press

Hydraulic Core Press

Hydraulic Core Press

'C' Frame / Open Throat Hydraulic Press
