We are Manufacturer, Supplier, Exporter of: Hydraulic Nut Splitters (PHNS-Series) from Belgaum, Karnataka, India.
Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.
Features / Benefits :- Single acting, Light weight, Compact, easy to use
- Cylinder honed to a surface finsh of 0.4 microns
- Noiseless in operation
- Replaceable chisel
- Used in petrochemicals, marine, steel plant, constructions, Railways, Hydro projects, Nuclear Plants & Cement Plant.
- QCC with plastic dust cap. Aluminium Dust cap on Request.
Application :
Technical Specification :
These are used to cut corroded & jammed Nuts.
Technical Specification :
Model No. PHNS |
5 |
11 |
16 |
22 |
32 |
50 |
90 |
150 |
200 |
Max. Capacity (Tons) |
5 |
11 |
16 |
22 |
32 |
50 |
90 |
150 |
200 |
Max. Stroke (MM) |
18 |
18 |
20 |
25 |
30 |
30 |
35 |
55 |
55 |
Min. Nut across flat (MM) |
13 |
19 |
24 |
32 |
41 |
50 |
60 |
75 |
110 |
Max. Nut across flat (MM) |
19 |
24 |
32 |
41 |
50 |
60 |
75 |
105 |
130 |
Min. Size Nut ( Metric ) M |
8 |
12 |
16 |
22 |
27 |
33 |
39 |
45 |
76 |
Max. Size Nut ( Metric ) M |
12 |
16 |
22 |
27 |
33 |
39 |
48 |
72 |
90 |
