Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.

Threaded Ram, Load Return Hydraulic Jacks ( TLR-Series )

Capacity : 600 - 1000 tons, Stroke : 100 - 150 mm, Working : 700 bar ( Max )

Threaded Ram, Load Return Hydraulic Jacks
Threaded Ram, Load Return Hydraulic Jacks
Load Return Hydraulic Jack

pdf_button2

Features / Benefits
High strength, Heat treated alloy steel body.
Blackodised ram.
Single acting load return, Threaded ram with mechanical safety lock-nut.
Adequate gripping by grooved saddle.
High pressure long life seal.
Bottom mounting holes for bolting.
QCC with Plastic dust cap. Aluminum dust cap on Request.
Customised higher capacity, strokes and tilting saddle available on request.
Port Size 3/8" NPT.

Application : These jacks are ideally used for lifting of girders, pile testing for bridges and building foundation, handling of heavy duty machineries, kiln lifting, steel fabrication, ship building where lifted load is kept for longer period.

MODEL NO.
Capacity
Closed HT. 'H'
Stroke 'S'
Ram Dia 'RD'
Outer Dia 'D'
Oil Volume
Approx Weight
Suitable Hand Pump
tons.
mm.
mm.
mm.
mm.
cc.
kgs.
TLR 600 / 100 600 460 100 280 440 9534 480 PHP 500 / 16*PP
TLR 600 / 150 600 510 150 280 440 14073 525 PHP 500 / 16*PP
TLR 800 / 100 800 490 100 300 510 12544 700 *PP
TLR 800 / 150 800 540 150 300 510 18516 760 *PP
TLR 1000 / 100 1000 555 100 350 570 17700 950 *PP
TLR 1000 / 150 1000 585 150 350 570 24652 1050 *PP
