Threaded Ram, Spring Return Hydraulic Jacks
enquiry button

Though the specified capacity & stroke of the jacks are designed for maximum safe working, we recommend to use the jacks for 85% of its rated capacity & stroke as safe working practice and for long life of the jacks.

Threaded Ram, Spring Return Hydraulic Jacks (LTS-Series)

Capacity : 10 - 500 tons, Stroke : 50 - 150 mm, Working : 700 bar ( Max )

Threaded Ram, Spring Return Hydraulic Jacks
Threaded Ram, Spring Return Hydraulic Jacks
Threaded Ram, Spring Return Hydraulic Jacks


Features / Benefits
Hight strength, Heat treated alloysteel body
Blackodised ram.
Hight pressure long life seals.
Single acting spring return for smooth lowering. Threaded ram with mechanical safety lock-nut to sustain load on lock-nut for longer period
Bottom mounting holes for bolting.
Port Size 3/8" NPT.
Adequate gripping by grooved saddle
QCC with Plastic dust cap.
Custom strokes and tilting saddle available on request
Aluminum dust cap on request

Application : These jacks are an excellent choice for maintenance ideal for wide range of applications at construction site, mills, kiln lifting in steel, cement & process plants railway workshops, power plants, transformer lifting and industrial maintenance where lifted load is kept for longer period.

MODEL NO.
Capacity
Closed Ht. 'CH'
Stroke 'S'
Ram Dia 'RD'
Outer Dia 'D'
Oil Volume
Approx Weight
Suitable Hand Pump
tons.
mm.
mm.
mm.
mm
cc.
kgs.
LTS 10/50
10
160
50
40
65
80
3
PHP 200/2
LTS 10/100
10
210
100
40
65
164
4.5
PHP 200/2
LTS 10/150
10
260
150
40
65
243
5.5
PHP 200/2
LTS 15/50
15
170
50
45
70
119
4.2
PHP 200/2
LTS 15/100
15
220
100
45
70
247
5.0
PHP 200/2
LTS 15/150
15
270
150
45
70
366
6.0
PHP 200/2
LTS 20/50
20
180
50
55
80
116
6.0
PHP 200/2
LTS-20/100
20
230
100
55
80
324
7.0
PHP 200/2
LTS 20/150
20
280
150
55
80
480
8.0
PHP 200/3
LTS 25/50
25
200
50
65
90
192
8.0
PHP 200/2
LTS 25/100
25
250
100
65
90
404
10.0
PHP 200/3
LTS 25/150
25
300
150
65
90
596
11.5
PHP 200/3
LTS 30/50
30
200
50
70
100
276
10.0
PHP 200/2
LTS 30/100
30
250
100
70
100
528
12.0
PHP 200/3
LTS 30/150
30
300
150
70
100
779
14.5
PHP 200/3
LTS 50/50
50
215
50
85
130
432
23.0
PHP 500/6
LTS 50/100
50
265
100
85
130
870
21.5
PHP 500/6
LTS 50/150
50
315
150
85
130
1209
25.3
PHP 500/6
LTS 75/50
75
230
50
95
156
566
26.0
PHP 500/6
LTS 75/100
75
280
100
95
156
1188
26.4
PHP 500/6
LTS 75/150
75
300
150
95
156
1753
38.0
PHP 500/6
LTS 100/50
100
250
50
120
176
770
62.0
PHP 500/6
LTS 100/100
100
300
100
120
176
1616
45.0
PHP 500/6
LTS 100/150
100
350
150
120
176
2386
55.0
PHP 500/6
LTS 150/1006
150
315
100
140
226
2383
80.0
PHP 500/6
LTS 150/150
150
365
150
140
226
3518
95.0
PHP 500/12
LTS 200/100
200
330
100
160
256
3300
110.0
PHP 500/12
LTS 200/150
200
380
150
160
256
4874
125.0
PHP 500/12
LTS 250/100
250
345
100
180
286
3991
150.0
PHP 500/12
LTS 250/150
250
395
150
180
286
5892
160.0
PHP 500/12
LTS 300/100
300
360
100
200
315
4746
190.0
PHP 500/12
LTS 300/150
300
410
150
200
315
7012
204.0
PHP 500/16
LTS 400/100
400
400
100
220
355
6465
252.0
PHP 500/20*PP
LTS 400/150
400
450
150
220
355
9544
285.0
PHP 500/20*PP
LTS 500/100
500
425
100
250
405
7925
373.0
PHP 500/20*PP
LTS 500/150
500
475
150
250
405
11699
350.0
PHP 500/20*PP
